TOE 7608 Broadband Amplifier

TOE 7608 Broadband Amplifier

Product Overview Function/signal generators generally provide signals with a small amplitude into 50-Ohm systems. Signal conditioning and amplification are therefore required in many technical areas. The TOE 7608 broadband amplifier is suitable as a non-inverting power output stage for the...

Description

Product Overview

Function/signal generators generally provide signals with a small amplitude into 50-Ohm systems.

Signal conditioning and amplification are therefore required in many technical areas.

The TOE 7608 broadband amplifier is suitable as a non-inverting power output stage for the amplification of such signal sources. Each generator with an output voltage of 20 Vpp is able to cover the full operating range of the TOE 7608 amplifier; the power is 63 W into 8 Ohm at a max. output amplitude of 45 Vpp. The bandwidth is DC to 500 kHz.

Overcurrent protection at the output, protection against feedback voltages, and over temperature protection provide the amplifier with a high degree of operational safety.

Key Features

  • Frequency range DC to 500 kHz
  • Short-circuit and no-load proof
  • Feedback voltage protection up to 120 V

Application Notes

Manufacturer

Downloads

There is no technical specification to download at this time, if you would like more information regarding this product please click here
