These shunts are used for the measurement of impulse currents in high-voltage test labs. The wave shape of the measured current can be displayed on a HAEFELY highest resolution impulse analysing system HiAS 744. The shunts consist of a metal cylinder with coupling flanges and a coaxial measuring connector.

The set of shunts type SH-H consist of Interchangeable low-inductive resistor-sleeves that can be built into the metal cylinder. A set consists of one cage and three sleeves of 2, 5 and 10 Ohm. The standard repetition rate allows measuring impulse currents up to 250 A (voltage drop 500 V), and at reduced repetition rate up to 800 A are possible (voltage drop 1600 V)

Applications
