R&S FSC Spectrum Analyzer

Product enquiry for R&S FSC Spectrum Analyzer

More InfoQuote

Frequency Range: 9 kHz – 3 GHz or 6 GHz

The R&S FSC is a compact, cost-efficient solution that offers all essential features of a professional spectrum analyzer with Rohde & Schwarz quality. It covers a wide range of applications from simple development tasks to production, or can be used for training RF professionals. Moreover, it is ideal for applications in service or maintenance. The R&S FSC features a wealth of functions for simplifying and speeding up the development and testing of RF products. Its good RF characteristics and its high measurement accuracy help to ensure reliable and reproducible measurement results.

Four different R&S FSC models are available in the frequency range from 9 kHz to 3 GHz or 6 GHz. Separate models with tracking generator are available for each frequency range. An optional pre-amplifier that is available for all models increases sensitivity for measuring weak signals.

Owing to its compact design, the R&S FSC takes up only a minimum of space on a lab bench. When installed in a rack, two R&S FSC or one R&S FSC and one R&S SMC signal generator situated next to each other fit into the 19” space.

Easy operation

The R&S FSC is operated via the keyboard and a rotary knob with an integrated enter function. All important settings such as frequency, bandwidth, span or marker can be directly accessed via hardkey buttons. Clearly arranged softkeys at the lower edge of the touch screen provide additional menu selections. The user interface is available in different languages: English, Korean, Japanese, Chinese, Russian, Italian, Spanish, Portuguese, French, Hungarian and German.

Key Features

  • Frequency range 9 kHz to 3 GHz or 6 GHz
  • Resolution bandwidths 10 Hz to 3 MHz
  • High sensitivity (< –141 dBm (1 Hz), with optional preamplifier < –161 dBm (1 Hz ))
  • High third order intercept (> 10 dBm, typ. 15 dBm)
  • Low measurement uncertainty (< 1 dB)
  • Low measurement uncertainty (< 1 dB)
  • Storage of measurement results on USB stick
  • LAN and USB interface for remote control and transfer of measurement data
  • R&S®FSCView software for simple documentation of measurement results
  • Compact dimensions
  • Low power consumption 12 W
  • Data transfer between the R&S®FSC and a PC via USB/LAN
  • Easy postprocessing of measurement results by means of data export in ASCII or MS Excel format
  • Storage of graphics data in standard formats
  • Printout of measurement results, including the instrument settings used
