Tektronix 2230-60-3 Programmable DC Power Supply

Tektronix 2230-60-3 Programmable DC Power Supply

The Series 2230 3-channel programmable power supplies provide up to 375 W of power in a space-saving 2U high, half-rack width enclosure to power automotive circuits, LED drivers, power supplies, power ICs, and other highpower circuits. The 2230-30-6 and the 2230-60-3 supplies output as much as 375 W. The 2230-60-3 has two 60 V, 3 A channels, both 375 W supplies have a 5 V, 3 A channel as the third channel.

These three supplies are linear power supplies; thus, they are low noise supplies to have minimal impact on a device-under-test (DUT). Each channel has a rectangular output characteristic to enable obtaining the full current at the maximum voltage so that the 2230-30-6 can supply 30 V to a 6 A load and the 2230-60-3 can supply 60 V to a 3 A load.

Applications

  • High power analog ICs
  • Automotive circuits
  • Telecom infrastructure circuits
  • LED driver circuitry
  • Wide Bandgap modules

SKU: 2230-60-3 Category:

Key Features

  • 375 W models have two 30 V, 6 A channels or two 60 V, 3 A channels and one 5 V, 3 A channel
  • All channels are independently controlled and are isolated to power a wide range of test setups
  • All channels have remote sensing so the programmed voltage is accurately applied to the load
  • Set and monitor output voltages with 0.03% basic accuracy and 1 mV resolution
  • Monitor load current with 0.1% basic accuracy and 1 mA resolution
  • Low noise, linear regulation with <1 mV rms ripple and noise
  • Combine channels in series to output as high as 60 V and in parallel with two or three channels to create capacity as high as 15 A (2230-30-6)
  • Voltage and current outputs of three channels are displayed simultaneously for immediate observation of each output state
  • USB and RS-232 interfaces and rear panel connections for automated test convenience
