HMF2525 [HMF2550]25MHz [50MHz]

HMF2525 [HMF2550]25MHz [50MHz]

These instruments are high performance precision measuring instruments & devices for research and development labs, industry, universities, test and production facilities as well as for service, and are ideally suited for test installations in production and automated tests in laboratories.
They support either an USB/RS-232, or an IEEE-488 (GPIB) interface and thus may be easily integrated in any test system. In combination with other HAMEG remote controlled instruments high performance test systems may be easily and cost effectively set up. Of course, any of these instruments can be operated manually and used in laboratories.

Category:

Key Features

  • Frequency Range 10 µHz…25 MHz [50 MHz]
  • Output Voltage 5 mVpp…10 Vpp (into 50 Ω) DC Offset ±5 mV…5 V
  • Arbitrary Waveform Generator: 250 MSa/s, 14 Bit, 256 kPts
  • Sine, Square, Pulse, Triangle, Ramp, Arbitrary Waveforms incl. Standard Curves (white Noise, Cardiac etc.)
  • Total Harmonic Distortion 0.04 % (f <100kHz)
  • Burst, Sweep, Gating, external Trigger
  • Rise Time
  • Pulse Mode: Frequency Range 100 ?Hz…12.5 MHz [25 MHz], Pulse Width 15 ns…999 s, Resolution 5 ns
  • Modulation Modes AM, FM, PM, PWM, FSK (int. and ext.)
  • 10 MHz Timebase: ±1 ppm TCXO, rear I/O BNC Connector
  • Front USB Connector: Save and Recall of Waveforms and Settings
  • 8.9 cm (3.5″) TFT: crisp Representation of the Waveform and all Parameters
  • USB/RS-232 Dual-Interface, optional Ethernet/USB
  • Dual-Interface or IEEE-488 (GPIB)
